SN1100mm * 600mm Aluminum Square Truss Multi-purpose And Flexible For Concert
| Place of Origin | Guangzhou , China |
|---|---|
| Brand Name | LEDIKA |
| Certification | CE/SGS/TUV/ISO9001/ROHS |
| Model Number | Aluminum Square Truss |
| Minimum Order Quantity | 1 set |
| Price | Negotiation |
| Packaging Details | Carton with film |
| Delivery Time | 15 days after received the deposit |
| Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability | 50,000 meter /month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Model | Aluminum Square Truss | Material | 6082 |
|---|---|---|---|
| Usage | Lighting Truss For Decoration | Service | 24 Hours |
| Color | Silver Or OEM | ||
| Highlight | aluminum trusses,spigot truss |
||
Product Description
SN1100mm * 600mm Aluminum Square Truss Multi-purpose And Flexible For Concert
Product analysis:
This is the biggest size in our whole truss system now.It is developed for those applications and circumstances where no current truss solution will fit meet your deemand . The SN1100*600 is mainly for the towers or other support structures .
The main characteristics are compactness, optimum strength and easy assembly with the box corner system .It offers a flexible and strong truss system that is suitable for many designers .
| SN1100*600mm Square Truss Load Table (unit:mm) | ||||||
| Span | 8 | 16 | 25 | 32 | 38 | 44 |
| Centre Point Load | 6500 | 3000 | 1950 | 1200 | 950 | 650 |
| Deflection | 13 | 52 | 90 | 220 | 320 | 230 |
| Distributed Load | 1250 | 6000 | 3900 | 2500 | 1900 | 1400 |
| Deflection | 15 | 65 | 107 | 259 | 360 | 500 |
| Size | W*D*H:SN1100mm*600mm*1000mm--4000mm |
| Material | Aluminum 6082-T6 16 degree |
| Model Number | SN1100mm*600mm |
| Brand Name | |
| Main Tube | 60mm*7mm |
| Sub-main tube | 50mm*4mm |
| Brace tube | 32mm*3mm |
| Place of Origin | China (Mainland) |
| China (Mainland) | Guangdong |
| Name | Square Spigot Aluminum Truss |
| Profile | Aluminum Alloy |
| Loading Capicity | Safe Reach to 24m with 1000kg Average |
| Shape | Square |
| Usage | For Event And Exhibition |
| Color | Silvery and black or customized |
| Type | Spigot |
| Certification | TUV,CE,SGS |
| Size | irregularity size ,as customer request |
| Feature | High Corrosion Resistance , easy to install and demount , long service life , recyclable , multi-purpose , high loading capacity |
| Characteristics | Durable , high loading capacity.Raw material is aprecipitation hardening aluminum alloy,galvanization , containing magnesium and silicon as its major alloying elements . It has good mechanical properites, exhibits good weldability. It also has good effect of Proof Stress , corrosion resistance, antioxidation. |
| Truss system: | to hold events( for light, LED, speaker, audio, and so on) |
| Custom lenghts and shapes in metric and imperial sizes are available on request. | |
Advantage :
1) High stability aluminum alloy in 6082-T6
2) Good price with free connection with conical connector
3) excellent at after service. It can offer 1 years warranty,parts and technology will be offered for free.
aluminum truss are commonly used in a variety of different fields.Our products are easy to set up and give our customers great variety of possible installations.Our truss are commonly used for all kinds of applications such as truss lighting designs,exhibition booths,exhibit booths,trade show displays,booths for trade show,design booths,trade show banners,displays for trade show and many possible variations of expo booths overall from small one to the largest ones possible.
Why choose LEDIKA Truss ?
1. 16-year's experience in truss and stage industry.
2. Customers from more than 150 countries.
3. We are manufacture, can offer you lower price.
4. Professional engineers offer technical support to customers.
5. 24hours online services from our professional foreign trade department.
6. All our raw material is from public company.
7. Our complete QC system can make sure every product with high quality.
Choosing LEDIKA Truss, you will get not only the products, but also the better service, and better operating mode.
FAQ :
Q. Does LEDIKA accept OEM/ODM service ?
Yes , you can custom design or selected our design (OEM /ODM is high welcome) , our factory have professional design team and can do as your offered design .
Q.How to get samples from LEDIKA?
a.If you need samples for quality check , sample fees should be charged from buyer .
b.Free sample are available when order confirmed.
c.Most of the sample fees will be returned to you when order confirmed.
Q. What is the delivery time ?
7-15 days for batch goods regular size truss are in stock . Urgent order is also available.
Q. What is your trade terms?
Our trade terms are Ex-work , FOB , CNF & CIF
Q. Where is your factory and how can I visit your company ?
Ledika is a professional manufacturer in stage equipment, located in Nansha ,Guangzhou ,GuangDong , China . Warmly welcome you come to visit our factory .
Q. What advantage do you have to make me choose LEDIKA stage truss ?
We are a true factory & specialized in producing aluminum truss & other performance equipment more than 13 years . Humanist ans innovation are our base to develop, and we offer the best sale service for you.
